Komponen Elektronika dan Hobi Robot

Harga Rp. 60.000 (harap kontak untuk cek ketersediaan produk) harga diluar ongkir Isi Paket 1 USBASP Programmer (Double Power 3.3V/5V) 1 Usb Cable (10 pins) Product Description This programmer is based on Thomas Fischl’s USBasp design and connects to your computer’s USB port. Not only is it quite compact, but the design is really elegant  The USB interface is achieved by using an atmega processor and the rest is done in firmware. For those interested, the firmware source code can be downloaded from the USBasp website. Features 3.3V/5V double voltage supports, double protection Auto speed Support latest S52, latest firmware. Supported ICs: 51 Series：AT89S51 AT89S52 AT89S53 AT89S2051A T89S4051 AVR Mega Series: ATmega8 ATmega48 ATmega88 ATmega168 ATmega328 ATmega103 ATmega128 ATmega1280 ATmega1281 ATmega16 ATmega161 ATmega162 ATmega163 ATmega164 ATmega169 ATmega2560 ATmega2561 ATmega32 ATmega324 ATmega329 ATmega3290 ATmega64 ATmega640 ATmega644 ATmega649 ATmeg

Harga: Ask (Stock Available - 10) Harga diluar ongkir Isi Paket 1 AT24C256 (256Kb) EEPROM Data Module (I2C Bus) + Kabel Product Description EEPROM can store data permanently unless you erase, and won’t lost when power off. Normal Arduino only have 512 bytes data space, it won’t be enough, but maybe you think a gigabyte SD card is too much. Than this 256Kb EEPROM will be very suitable for small mount of data storage. Documentation Read more about EERPOM on wiki . Arduino Standard EEPROM tutorial . Schematic Features Imported chip, chip above the underlying code: 2ECL capacity of 256kb Onboard chip AT24C256 chips; Onboard I2C pull-up resistors are included for communication; All pins are leads and marked; PCB board size: 36.5 (mm) x12 (mm)

Klik untuk memesan / cek ketersediaan stok), harga Rp30.000,- ( Harga diluar ongkir ): DS1302 RTC module with CR1220 Holder http://www.vcc2gnd.com/2014/01/DS1302-RTC-Module.html DS1302 Introduction DS1302 DALLAS introduced trickle charge clock chip contains a real-time clock / calendar and 31 bytes of static RAM, communicate via a simple serial interface with microcontroller. Real-time clock / calendar circuit provides a second, minute, hour, day, week, month, year, the monthly number of days and a leap year, the number of days can be automatically adjusted. The clock can be done by the AM / PM indicator decided to use 24 or 12-hour format. DS1302 between the microcontroller and simple synchronous serial communication only used three-port line: (1) RST Reset (2) I / O data lines (3) SCLK serial clock. Clock / RAM read / write data to a byte or character group by up to 31 bytes of communication. The DS1302 Low power consumption to maintain data and clock information when th

Harga Rp. 40.000 Harga diluar ongkir Isi Paket 1 module LM2596 DC-DC step down voltage regulator Product Specification Pins: IN + input positive IN-enter negative! OUT + output the positive OUT-output negative! Note that the input and output can not be reversed. Reverse may burn out! Feature: Input: DC 3V to 40V, (input voltage must be higher than the output voltage to 1.5v) Output: DC 1.5V to 35V, voltage continuously adjustable, high-efficiency maximum output current of 3A. Features: All SANYO solid capacitors, the 36u thickening circuit boards, high-Q inductance, with output value of high-power LED indicator Dimensions: 45 (L) * 20 (W) * 14 (H) mm (with potentiometer), Smallest size you have ever seen, and with positioning holes, LED indicator DC-DC Module

Harga Rp. 40.000 Harga diluar ongkir , klik pada gambar untuk cek ketersedian stock: DS1307 I 2 C RTC Module + AT24C32 EEPROM 8 KB Module Feature: DS1307 I 2 C real-time clock chip (RTC) 24C32 32K I2C EEPROM memory Using LIR2032 rechargeable lithium battery with charging circuit Fully charged, it can provide 1 year lifetime. Compact design, 27mm * 28mm * 8.4mm Leads to the a DS1307 clock pin, to provide the clock signal for the MCU. Can be cascaded to other I2C devices. About DS1307 DS1307 is a low power, with 56 bytes of non-volatile RAM BCD code clock calendar real-time clock chip, the address and data transmission through the two-wire bidirectional serial bus, the chip can be seconds, minutes, hours and other information , the number of days in each month can be adjusted automatically. And there is a leap year compensation function. AM / PM flag determines clock work 24-hour or 12-hour mode, the chip has a built-in power-sense circuit, brownout detection and batte

Harga Rp. 50.000 (kontak terlebih dahulu untuk cek ketersediaan product) Harga diluar ongkir Isi Paket 1 SD Card Module Product Description 100% Brand new input voltage :3.3v/5v with all SD SPI Pins out :MOSI, SCK, MISO and CS ,for further connection Through programming, you can read and write to the SD card using your arduino make your SD application more easier and simple

Harga Rp. 35.000  Harga diluar ongkir Modul penerima Radio FM ini berukuran mikro yang sangat mungil, bandingkan dengan besar uang logam Rp1000,- yang disandingkan di samping modul ini. Untuk mengecek ketersediaan stok, lihat di katalog harga kami dengan meng-klik tautan berikut: Micro FM Radio Module TEA5767 Product Description A subminiature Low-power FM stereo radio module for any electronic application. Built-in Philips TEA5767 FM IC. High sensitivity with integrated low-noise RF input amplifier. Frequency range: 87.5Mhz-108Mhz. Suitable for handheld applications. Built in 32.768khz clock crystal. PLL tuning system. Dimension: 11.2mm x 11mm.

Harga Rp. 45.000  (harga diluar ongkir) Isi Paket:  1 PIR Sensor HC-SR501/V2 Klik pada gambar di atas untuk mengecek ketersediaan stok dan memesan PIR Sensor Human Motion Detector lewat katalog harga kami di toko komponen elektronika online Indonesia Vcc2GND.com Product Description HC-SR501 is based on infrared technology, automatic control module, using Germany imported LHI778 probe design, high sensitivity, high reliability, ultra-low-voltage operating mode, widely used in various auto-sensing electrical equipment, especially for battery-powered automatic controlled products. Specification: Use BISS0001 signal processing IC, sanyo genius regulator Voltage: 5V – 20V Power Consumption: 65mA TTL output: 3.3V, 0V Delay time: adjustable (0.3 sec – 10 minutes) Lock time: 0.2 sec Trigger methods: L – disable repeat trigger, H enable repeat trigger Sensing range: less than 120 degree, within 7 meters Temperature: – 15 ~ +70 Dimension: 32*24 mm, distance between

Harga Rp. 70.000 / paket (3 pcs). Product Description Size: 42mmx30mm Use ULN2003 driver chip, 500mA A. B. C. D LED indicating the four phase stepper motor working condition. White jack is the four phase stepper motor standard jack. Power pins are seperated We kept the rest pins of the ULN2003 chip for your further prototyping. Connections: IN1-4 to the MCU pins The pins in the white jack (from left to the right) are: VCC, A, B, C, D (to the stepper motor) Power pins are on the right, use jumper to choose either 5V or 12V.

Harga Rp. 45.000 (kontak lebih dahulu untuk cek stock) (harga diluar ongkir) Isi Paket 1 LCD Character 16 x 2 Product Description Use the arduino library at here arduino site. LCD display module with blue backlight Wide viewing angle and high contrast Built-in industry standard HD44780 equivalent LCD controller Commonly used in: copiers, fax machines, laser printers, industrial test equipment, networking equipment such as routers and storage devices LCM type: Characters Can display 2-lines X 16-characters Operate with 5V DC Module dimension: 80mm x 36mm x 12mm Viewing area size: 64.5mm x 16mm

Harga Rp. 250.000 (kontak lebih dahulu untuk cek stock) harga diluar ongkir Isi Paket 1 LCD TFT 2.4" 240x320 Specification Includes the SD card slot and touch panel function. Arduino supported, can be driven by Arduino, AVR, PIC, STM32 and most 8080 16bits MCUs. Includes the backpack PCB, 3.3-5V power regularing circuit. Supported by UTFT library except 7.0 is not yet fully tested. And some codes need to modify further due to some reasons, for example in the touch panel demo code, display on X+ and X- are mirror, so when you draw on left it comes to right, this changes on code will need to do it by yourself. Arduino Converter Shield TFT01 Arduino shield and TFT01 Arduino MEGA shield (recommand), you can directly plug the TFT01 LCD module in the shield and stand on the Arduino board.

SOLD OUT.. Akan diupdate setelah restock Harga: Rp. 45.000 (harap kontak untuk cek stock) (harga diluar ongkir) Isi Paket 1 x Gas Sensor This Arduino Gas Sensor can detect smoke, methane, carbon dioxide and other gases.It is capable of detecting various gases.This arduino-compatible special sensor raise alarms when the smoke, methane or any other harmful gas leaks in its reach. Arduino smoke gas sensor Detects smoke, methane, carbon dioxide and other gases Gives alarms when the smoke/gas leaks Power supply needs: 5V DC Specification Product Name Gas Sensor Model MQ-5 Sensor Type Semiconductor Detection Gas LPG, Methane, Coal Gas Concentration 300-10000ppm( Methane, Propane, Butane, H2) Circuit Loop Voltage(Vc): ≤24V DC Heater Voltage(Vh): 5.0V±0.2V AC or DC Load Resistance(Rl): Adjustable Character Heater Resistance(Rh): 31Ω±3ΩRoom Tem. Heater Consumption(Ph): ≤900mW Sensing Resistance(Rs): 2KΩ-20KΩ(in 2000ppm C3H8 ) Sensitivity(S): Rs(in air)/Rs(1000

READY STOCK Harga: Rp. 47.500 -  harga diluar ongkos kirim Isi Paket 1 Sensor probe 1 Detecting board 1 Set Connection Cables This is a simple water sensor can be used to detect soil moisture when the soil moisture deficit module outputs a high level, and vice versa output low. Use this sensor produced an automatic plant watering device, so that the plants in your garden without people to manage. Untuk mengecek ketersediaan stok dan melakukan pemesanan, silakan buka katalog produk kami untuk  Soil Moisture Hygrometer Sensor YL69/LM393 Product Specification Sensitivity adjustable the blue digital potentiometer adjustment Operating voltage 3.3V-5V Module dual output mode, digital output, analog output more accurate. With fixed bolt hole for easy installation Small board PCB size: 3cm * 1.6cm Power indicator (red) and digital switching output indicator (green) Comparator LM393 chip, very stable Connections VCC connect to 3.3V-5V GND connect to GND DO digita

Harga Rp. 55.000 (harap kontak untuk cek stock) Isi Paket 1 Module Sensor Ultrasonic Range Finder Reliable, high performance, high accuracy, blind area within 2cm Specification Voltage：DC5V Current：less 2mA TTL：higher 5V Sensing angle：Less than 15 degree Sensing distance：2cm-450cm Accuracy：about 0.3cm PCB Dimension：4.5*2.0CM Connection: VCC, trig(Control), echo(Receive), Out, GND Working principle Send high TTL signal at trigger IO. Module automatically send 8*40khz squre wave in order to detect if there are any signal return. when signal return, use each(receive) IO pin output high TTL, the output TTL time length is the time from sending till return. try to use this fomula: distance = (high TTL time* velocity of sound)/2 velocity of sound = 340m/s

Harga Rp. 75.000 (harap kontak terlebih dahulu untuk ketersedian stock) Isi Paket 1 Module Transceiver 1 Module Receiver Features The excellent performance of the receiver module, using a digital process technology, with a strong anti-interference, stable performance, high reliability, non-directional, long life, undisturbed Japan imported chips, high stability, low power consumptionsimilar remote control does not have any interference garbled phenomenon, the transmitted signal of the wireless receiver, remote control distance, can pass through walls, no direction. Supporting the use of any of the same frequency remote control can be and market fixed code, learning code. Super-regenerative receiver module LC oscillator circuit includes amplifier shaping output data signals to TTL level directly to the decoder, the use of extremely easy, and inexpensive, it is widely used. The small size, high sensitivity; frequency point debugging easy, short lead times; consistency of prod

Harga Rp. 110.000 Silakan cek status stok di: Toko Komponen Elektronika online Indonesia, jual RFID RC522 Mifare-One Isi Paket KIT RFID Reader 1 buah RFID-RC522 Module 1 buah Standard empty RC522 Card 1 buah RC522 Key 1 buah Break away pin straight 1 buah Break away pin 90 degree RC522 IC Brief Introduction MF RC522 is used in highly integrated 13.56MHz contactless communication card chip to read and write, of NXP for “three” and the application launched a low voltage, low cost, small size, non-contact card chip to read and write, intelligent instruments and portable handheld devices developed better. The MF RC522 use of advanced modulation and demodulation concept completely integrated in the 13.56MHz all kinds of passive contactless communication methods and protocols. 14443A compatible transponder signal. The digital part handles the the ISO14443A frames and error detection. In addition, support Quick CRYPTO1 encryption algorithm, the term verification MIFARE
